Eco Pellet Burning Stove (NPS45) #NPS45

Eco Pellet Burning Stove (NPS45)

Item #: NPS45

$0.00


Order Now

DESCRIPTION



GLASS/GASKET/DOOR


Item Description (Part Number)

39- EXHAUST GASKET (W290-0122) +$11.21 QTY:
48- ASH PAN (W010-1667) +$175.09 QTY:
48A- ASH PAN MAIN BODY GASKET (W562-0025) +$62.20 QTY:
48B- TAPE - ASH PAN GASKET ~Old Part #W667-0018~ (W667-0018-SER) +$15.99 QTY:

ITEMS NOT SHOWN - GLASS/GASKET/DOOR


Item Description (Part Number)

36- FRONT GLASS (W300-0038) +$209.68 QTY:
37- GLASS - RIGHT OR LEFT (W300-0037) +$75.35 QTY:
62- DOOR FRAME - BLACK (W225-0195) +$183.51 QTY:
62A- DOOR FRAME - GOLD (W225-0195G) +$836.02 QTY:
62B- DOOR FRAME - SATIN CHROME (W225-0195SC) +$1102.80 QTY:
80- GLASS GASKET [MUST REPLACE IF DISMANTLING GLASS ASSEMBLY] ~Old Part # W562-0022~ (W562-0009) +$111.25 QTY:
81- DOOR LATCH [2 per unit, each sold separately] (W390-0002) +$37.68 QTY:

FIREBOX COMPONENTS


Item Description (Part Number)

30- BURNER POT - CAST ROUND (W135-0320) +$79.90 QTY:
43- BURNER LOUVRE ASSEMBLY - RIGHT (W010-1673) +$55.38 QTY:
44- BURNER LOUVRE ASSEMBLY - LEFT (W010-1685) +$55.38 QTY:
82- BURN POT GASKET (W290-0126) +$11.21 QTY:

INTERNAL COMPONENTS


Item Description (Part Number)

1- LOW LIMIT SWITCH [140F] (W660-0052) +$99.88 QTY:
2- HIGH LIMIT SWITCH [220F] (W660-0169) +$37.68 QTY:
3- VACUUM SWITCH (W660-0056) +$68.20 QTY:
5- AUGER MOTOR (NPAM) +$281.33 QTY:
6- CONVENCTION BLOWER [W290-0113 INCLUDED] (PSCB) +$504.08 QTY:
10- GASKET - CONVECTION BLOWER (W290-0113) +$11.21 QTY:
7- EXHAUST BLOWER ASSEMBLY [W290-0111 INCLUDED] ~Old Part # W062-0027~ (W062-0027-SER) +$401.59 QTY:
8- GASKET - EXHAUST BLOWER TO HOUSING (W290-0111) +$11.21 QTY:
9- GASKET - EXHAUST BLOWER & HOUSING TO FIREBOX (W290-0120) +$11.21 QTY:
15- AUGER (W570-0107) +$154.31 QTY:
15A- TEFLON BUSHING, AUGER [2 per unit, each sold separately] (W105-0012) +$11.21 QTY:
15B- RETAINER - AUGER SHAFT (W500-0501) +$11.56 QTY:
21- IGNITOR (W010-1949) +$398.53 QTY:
24- IGNITOR KIT (W010-1949-SER) +$504.08 QTY:
26- CONTROL HOUSING (W350-0361) +$59.93 QTY:
27- MOTOR BRACKET (W080-0932) +$34.37 QTY:
28 - COMBUSTION AIR TUBE ASSEMBLY (W010-1491) +$104.43 QTY:
33- IGNITION GASKET (W290-0119) +$11.21 QTY:
34- RECEPTACLE (W460-0004) +$18.38 QTY:

ITEMS NOT SHOW - INTERNAL COMPONENTS


Item Description (Part Number)

11- PRESSURE FITTING TAP (W225-0020) +$Call to Order QTY:
23 - EXHAUST TUBE (W010-1490) +$Call to Order QTY:
32- MOTOR MOUNTING GASKET (W290-0120) +$11.21 QTY:
60- SWITCH - HOPPER [NPI45] (W660-0084) +$90.78 QTY:
61- WIRE - JUMPER [TGGT] [NPI45] (W750-0230) +$36.99 QTY:
67- DECROATIVE LOG SET [NPI45] (NPL41) +$305.63 QTY:
83- ELECTRONIC CONTROL BOARD (W190-0036) +$518.75 QTY:
84- HOPPER INTERLOCK SWITCH (W660-0083) +$57.65 QTY:
85- WIRING HARNESS (W750-0215) +$163.71 QTY:

EXTERNAL COMPONENTS


Item Description (Part Number)

13- ASH PAN DOOR LATCH [2 per unit, each sold separately] (W390-0022P) +$Call to Order QTY:
14- SCRAPER ROD (W555-0061) +$36.75 QTY:
16- COTTER PIN [AUGER MOTOR] (W485-0038) +$11.21 QTY:
22- CONTROL PANEL LATCH (W390-0012) +$77.63 QTY:
29- ACCENT ROD [2 per unit, each sold separately] (W030-0022P) +$104.43 QTY:
31- MAGNETIC DOOR CATCH ASSEMBLY [2 per unit, each sold separately] (W430-0002) +$29.59 QTY:
40- EXHAUST COLLAR (W010-1612) +$77.63 QTY:
41- EXHAUST COVER (W010-0219) +$Call to Order QTY:
45- WELDED TOP ASSEMBLY (W010-1508) +$138.55 QTY:
46- SIDE DOOR ASSEMBLY [2 per unit, each sold separately] (W010-1527) +$88.50 QTY:
47- HOPPER DOOR ASSEMBLY (W010-1529) +$162.01 QTY:
49- PEDESTAL SIDE DOOR ASSEMBLY [2 per unit, each sold separately] (W010-1668) +$106.70 QTY:
50- PEDESTAL BASE (W035-0191) +$159.39 QTY:
59- OUTER PANEL - REAR (W475-0482) +$120.35 QTY:
51- OUTER PANEL - RIGHT ~Old Part # W475-0484~ (W475-0609) +$120.35 QTY:
52- OUTER PANEL - LEFT (W475-0485) +$106.70 QTY:
56- HOPPER SWITCH (W660-0176) +$62.20 QTY:
69- 8 INCH BLACK FLASHING WITH BLACK TRIM (NI800) +$Call to Order QTY:

ITEMS NOT SHOWN - EXTERNAL PARTS


Item Description (Part Number)

4- POWER CORD (W195-0004) +$57.65 QTY:
17- WIRE HARNESS (W750-0383) +$140.82 QTY:
18- LOGO - NAPOLEON (W385-2010) +$23.15 QTY:
19- SIDE DOOR ASSEMBLY [LEFT OR RIGHT] ~Old Part #W010-1528~ (W010-1527) +$88.50 QTY:
20- BOTTOM ORNAMENTAL INSERT PANEL (W475-0555) +$124.90 QTY:
54- PEDESTAL GASKET (W562-0048) +$Call to Order QTY:
57- SIDE DOOR ASSEMBLY [NPI45] (W010-1670) +$102.15 QTY:
58- WELDED HOPPER LID ASSEMBLY [NPI45] (W010-1991) +$403.77 QTY:
63- TRIVET - GOLD (GS200-G) +$140.00 QTY:
63A- TRIVET - SATIN CHROME (GS200-SS) +$170.00 QTY:
64- PRORCELAIN REFLECTIVE RADIANT PANELS (PRPP40) +$Call to Order QTY:
65- OUTSIDE AIR KIT - 5 FT [2 INCH DIA.] (114KT) +$110.00 QTY:
68- HOPPER EXTENSION [INCREASES HOPPER CAPACITY FROMM 55 LBS TO 100 LBS PELLETS] (NPHE40-1) +$194.25 QTY:
70- ARCHED CAST IRON SURROUND (GICSK) +$545.00 QTY:
71- ADAPTER KIT [REQUIRED FOR GICSK] (AK8) +$Call to Order QTY:
72- CAST IRON SURROUND KIT - BLACK (CISM) +$670.00 QTY:
72A- CAST IRON SURROUND KIT - MAJOLICA BROWN (CISKN) +$875.00 QTY:
72B- CAT IRON SURROUND KIT - MAJOLICA BLUE (CISKB) +$Call to Order QTY:
72C- CAST IRON SURROUND KIT - MAJOLICA GREEN (CISKF) +$Call to Order QTY:
73- ADAPTOR KIT [REQUIRED FOR CISK] (AK9) +$Call to Order QTY:
74- ASH PAN RAIL [2 per unit, each sold separately] (W525-0009) +$37.68 QTY:
75- POT SCRAPER TOOL (W600-0002) +$39.95 QTY:
76- TRIVET - BLACK (W010-2511) +$97.60 QTY:
77- PAINT - METALLIC BLACK (209M) +$82.18 QTY:
78- INSTRUCTION MANUAL [hard copy] [W415- 0702] (OMHC-N) +$21.99 QTY:
79- INSTRUCTION MANUAL [electronic copy] [W415- 0702] (OMEL-N) +$9.99 QTY:
