MAIN ASSEMBLY
Item Description (Part Number) 8 TRAY ASH [HMF150/200] (W710-0033) +$Call to Order QTY: 9 LATCH 2 STAGE (W390-0029) +$Call to Order QTY: 9 DOOR HANDLE - LATCH ASSEMBLY [NO SPRING HANDLE] (W020-0078) +$109.27 QTY: 14 KNOB N - ASH/HEAT EXCH DOOR (W380-0023) +$Call to Order QTY: 15 SECONDARY AIR TUBE [HMF150] [4 per unit, each sold separately] ~Old Part # W720-0157~ (W720-0157-SER) +$121.93 QTY: 15A BRACKET - CONTROL ROD SUPPORT [HMF150] (W080-1104) +$Call to Order QTY: 16 SECONDARY AIR TUBE COTTER PIN [4 per unit, each sold separately] (W485-0034) +$37.31 QTY: 17 GRATE - CAST IRON (W185-0002) +$70.27 QTY: 18 ASSEMBLY - DAMPER LINKAGE [HMF150] (W010-2406) +$Call to Order QTY: 19 DAMPER DRAFT OPER 2 POSN SPRING RETURN (W435-0003) +$Call to Order QTY: 20 PLATE - SHUTTER [HMF150] (W500-0534) +$Call to Order QTY: 21 TRANSFORMER 120/24V 40VA (W010-2572) +$Call to Order QTY: 22 ROCKER SW SUMMER SW (W660-0090) +$Call to Order QTY: 23 ROCKER SW OIL/ELEC (W660-0089) +$Call to Order QTY: 24 INTERLOCK RELAY (RSB2A080B7) +$Call to Order QTY: 25 TRANSFORMER RELAY SPNO 24V COIL 90-360 (W660-0150) +$Call to Order QTY:
ITEMS NOT SHOWN - MAIN ASSEMBLY
Item Description (Part Number) 26 ADD-ON RELAY (RSB2A080F7) +$Call to Order QTY: 27 FAN/LIMIT RELAY SPDT 120V COIL 90-294Q (W660-0149) +$Call to Order QTY: 28 GLASS & GASKET (W010-1071) +$262.55 QTY: 29 GLASS GASKET KIT (W020-0050) +$64.70 QTY: 30 DOOR - CAST (W225-0259) +$Call to Order QTY: 31 SECONDARY HAIR PIN COTTER PIN (W485-0047) +$14.28 QTY: 32 ASSEMBLY - ELECTRIC CONTROL KIT C/HMF (W010-3464) +$Call to Order QTY: 33 FAN LIMIT SENSOR - WOOD (W010-3463) +$Call to Order QTY: 34 FAN LIMIT SENSOR - OIL (W010-3746) +$Call to Order QTY: 35 FAN CENTRE [WHITE RODGERS] (W707-0013) +$Call to Order QTY: 36 PRIMARY AIR SHUTTER RETRO FIT KIT (W370-0100) +$Call to Order QTY: 37 ASSEMBLY PRIMARY AIR DAMPER [HMF150] (W010-2407) +$Call to Order QTY: 38 FAN LIMIT SWITCH - WOOD (W010-3025) +$Call to Order QTY: 39 FAN LIMIT SWITCH - OIL (W010-3026) +$Call to Order QTY: 40 BLOWER MOTOR CAPACITOR (W435-0014) +$Call to Order QTY: 41 BLOWER MOTOR (W435-0030) +$Call to Order QTY: 42 BRUSH - 5 INCHES POLY SWEEP 3/8 INCH NSPM (W085-0001) +$Call to Order QTY: 43 BRUSH ROD - 1.5 METERS FIBERGLASS EXT 3/8 INCHES NSPM (W085-0002) +$Call to Order QTY: 44 GEAR - SPLIT LEATHER GLOVE (62140) +$112.92 QTY: 45 SHIELD - SS AIR WASH HEAT [HMF150] (W585-0782) +$Call to Order QTY: 46 GASKET - AIR WASH (W290-0216) +$Call to Order QTY: 47 BRACKET - SS AIR WASH (W080-1275) +$Call to Order QTY: 48 SCREW - 1/4 INCH -20 x 3/8 INCH HEX HD (W570-0007) +$39.26 QTY: 49 TRAY - ASH COMPARTMENT (W710-0032) +$Call to Order QTY: 50 KIT -SEC. MANIFOLD SHIELD (W370-0030) +$Call to Order QTY: 51 ASSEMBLY ASH DOOR (W010-2360) +$Call to Order QTY: 52 HANDLE - BLACK WIRE [LARGE] (W325-0043) +$37.31 QTY: 53 DOOR PIN - 3/8 x 2 INCHES [2 per unit, each sold separately] (W545-0003) +$43.15 QTY: 54 DOOR PIN - 3/8 x 4 INCHES [older doors] (W485-0041) +$Call to Order QTY: 55 FILTER RACK [NO FILTER] (W280-0175) +$Call to Order QTY: 56 SWITCH RELAY SPNO 24V COIL OIL BURNER (W660-0150) +$Call to Order QTY: 57 SOLID DOOR INSERT KIT (W010-2536) +$Call to Order QTY: 58 SOLID DOOR FIBRE INSULATION (W361-0110) +$Call to Order QTY: 59 SOLID DOOR SS GUARD (W500-0725) +$Call to Order QTY: 60 DOOR RETAINING HARDWARE KIT (W020-0662) +$Call to Order QTY: 61 WMO THERMAL SAFETY SWITCH (HMFK-WMO) +$Call to Order QTY: 62 OIL BURNER GASKET KIT (W020-0661) +$Call to Order QTY: 63 HMF FURNACE COMPLETE GASKET KIT (W020-0660) +$Call to Order QTY: 64 INSTRUCTION MANUAL [hard copy] (OMHC-N) +$9.99 QTY: 65 INSTRUCTION MANUAL [electronic copy] (OMEL-N) +$0.00 QTY:
FIREBRICK
Item Description (Part Number) A FIREBRICK 1.25 INCHES x 4.5 INCHES x 9 INCHES [23 per unit, each sold separately] (W090-0015) +$20.42 QTY: B FIREBRICK 1.25 INCHES x 2.875 INCHES x 4.5 INCHES ]2 per unit, each sold separately] (W090-0180) +$Call to Order QTY: C FIREBRICK 1.25 INCHES x 4.5 INCHES x 6 INCHES [3 per unit, each sold separately] (W090-0181) +$Call to Order QTY: D FIREBRICK 1.25 INCHES x 4.5 INCHES x 4.5 INCHES [2 per unit, each sold separately] (W090-0003) +$43.15 QTY: E BAFFLE [set of 2] (W010-2410) +$332.73 QTY: F FIREBRICK 1.25 INCHES x 2.625 INCHES x 9 INCHES [2 per unit, each sold separately] (W090-0179) +$50.95 QTY: G FIREBRICK 1.25 INCHES x 4.25 INCHES x 6 INCHES [1 per unit] (W090-0186) +$Call to Order QTY: H FIREBRICK 1.25 INCHES x 4.5 INCHES x 8 INCHES [1 per unit] (W090-0200) +$Call to Order QTY: I FIREBRICK 1.25 INCHES x 4.5 INCHES x 4 INCHES [2 per unit, each sold separately] (W090-0199) +$Call to Order QTY: J FIREBRICK 1.25 INCHES x 4.5 INCHES x 8.5 INCHES [1 per unit, each sold separately] ~Old Part # W090-0184~ (W090-0210) +$23.15 QTY: K BRICK RETAINER 19.25 INCHES [2 per unit, each sold separately] (W080-1092) +$Call to Order QTY: L BRICK RETAINER 17.5 INCHES [2 per unit, each sold separately] (W080-1093) +$Call to Order QTY:
ITEMS NOT SHOWN - FIREBRICK
Item Description (Part Number) M FIREBRICK 1.25 INCHES x 1.5 INCHES x 6 INCHES (W090-0187) +$Call to Order QTY: N FIREBRICK 1.25 INCHES x 1.5 INCHES x 9 INCHES (W090-0188) +$Call to Order QTY:
|
