Havelock Direct & Natural Vent Gas Stove (GDS50) #GDS50

Havelock Direct & Natural Vent Gas Stove (GDS50)

Item #: GDS50

$0.00


Order Now

DESCRIPTION



MAIN BODY


Item Description (Part Number)

2- DOOR FRAME - METALLIC BLACK (W225-0086) +$663.24 QTY:
2A- DOOR FRAME - GOLD (W225-0086G) +$2,031.85 QTY:
2B- DOOR FRAME - SATIN CHROME (W225-0086SC) +$1,734.13 QTY:
5- PIEZO IGNITOR (W357-0001) +$35.36 QTY:
6- VALVE TRAIN ASSEMBLY (W010-1265) +$1,938.24 QTY:
7- CHARCOAL EMBERS (W135-0027) +$34.71 QTY:
8- LOG #1 - BASE LOG (W135-0194) +$158.70 QTY:
9- LOG #4 - LEFT CHUNK (W135-0197) +$100.20 QTY:
10- LOG #2 - MID CROSSOVER (W135-0195) +$30.61 QTY:
11- LOG #3 - RIGHT CROSSOVER (W135-0196) +$104.10 QTY:
12- LEFT SIDE DOOR ASSEMBLY (W010-3526) +$131.40 QTY:
13- DOOR MAGNET CATCH [2 per unit, each sold separately] (W430-0002) +$45.10 QTY:
14- RELIEF HOUSING GASKET (W290-0032) +$37.31 QTY:
15- BURNER TRAIN GASKET (W290-0031) +$47.05 QTY:
16- AIR MANIFOLD COVER GASKET (W290-0033) +$35.36 QTY:
17- AIR MANIFOLD COVER PLATE (W500-0111-SER) +$88.84 QTY:
18- NAPOLEON LOGO (W385-2010) +$43.15 QTY:
19- TRIVET ASSEMBLY (W010-2555M-SER) +$107.41 QTY:
20- ON/OFF SWITCH ~Old Part #W660-0009-SER~ (W660-0009) +$66.56 QTY:
21- ON/OFF WIRES [45 INCH AND 42 INCH] (W020-0079) +$70.89 QTY:
22- VARIABLE SPEED SWITCH KNOB (W380-0002) +$31.46 QTY:
23- VARIABLE SPEED SWITCH (W660-0073) +$111.13 QTY:
24- BLOWER WITH GASKET (GDS-63) +$685.94 QTY:
25- RIGHT SIDE DOOR ASSEMBLY (W010-3525) +$133.10 QTY:
26- POWER CORD [7 FEET] (W750-0190) +$88.84 QTY:
27- DOOR LATCH [2 per unit, each sold separately] (W390-0001) +$50.95 QTY:
28- HEAT SENSOR ~Old Part #W690-0002~ (W690-0002-SER) +$57.27 QTY:

ITEMS NOT SHOWN - MAIN BODY


Item Description (Part Number)

50- SAFETY BARRIER ASSEMBLY (W565-0196-SER) +$1,674.27 QTY:
51- CONTROL DOOR ASSEMBLY (W010-3524) +$122.89 QTY:
52- GLASS - FRONT (W300-0029) +$250.09 QTY:
53- GLASS - RIGHT OR LEFT (W300-0028) +$94.41 QTY:
54- LOG SET (GL-642) +$381.83 QTY:

VALVE TRAIN ASSEMBLY


Item Description (Part Number)

29- BURNER GASKET (W290-0030) +$43.15 QTY:
30- BURNER ORIFICE #43 [NG] TURBO (W455-0037) +$64.70 QTY:
31- BURNER ORIFICE #57 [LP] TURBO (W455-0034) +$60.99 QTY:
32- VALVE - TURBO - NG (W010-0087) +$162.01 QTY:
33- VALVE - TURBO - LP (W010-0175) +$78.63 QTY:
34- TURBO CONTROL KNOB (W380-0001) +$35.36 QTY:
35- VALVE - SIT - NG [AFTER S/N 016339] (W725-0042) +$442.36 QTY:
36- VALVE - SIT - LP [AFTER S/N 016339] (W725-0043) +$707.43 QTY:
37- PILOT GASKET (W290-0029) +$39.26 QTY:
38- PILOT HOOD (W335-0039) +$45.10 QTY:
39- PILOT Only - NG [SIT, no thermopile, thermocouple, or igniter][recommend using High Temp Red Silicone] (W010-0801) +$168.20 QTY:
40- PILOT Only - LP [SIT, no thermopile, thermocouple, or igniter][recommend using High Temp Red Silicone] (W010-0800) +$168.20 QTY:
41- PILOT ORIFICE #62 [NG] [PSE] (W455-0070) +$43.15 QTY:
42- PILOT ORIFICE #35 [LP] [PSE] (W455-0068) +$43.15 QTY:
43- THERMOCOUPLE [SIT AFTER SERIAL 13204] (W680-0005) +$59.13 QTY:
43A- THERMOCOUPLE [SIT] - [FOR BOTTOM LOAD PILOT ORIFICE ASSEMBLY] (W680-0006) +$164.64 QTY:
43B- THERMOCOUPLE [PSE] [BEFORE SERIAL 13203] (W680-0008) +$77.70 QTY:
44- THERMOPILE (W680-0004) +$114.84 QTY:
45- ELECTRODE WITH WIRE (W240-0006-SER) +$105.55 QTY:
46- PILOT TUBE WITH FITTINGS [SIT] (W720-0062) +$49.00 QTY:
46A- PILOT TUBE WITH FITTINGS [PSE] (W010-0586) +$40.63 QTY:
47- COMPLETE PILOT ASSEMBLY [NG] [SIT] (W010-0798) +$218.05 QTY:
48- COMPLETE PILOT ASSEMBLY [LP] [SIT] (W010-0799) +$218.05 QTY:

ITEMS NOT SHOWN - VALVE TRAIN ASSEMBLY


Item Description (Part Number)

55- MAIN BURNER [FRONT, TUBE] - NG/LP (W100-0040) +$151.98 QTY:
56- TURBO BURNER [REAR, TUBE] - NG/LP (W100-0046) +$209.15 QTY:
57- MAIN BURNER ORIFICE - NG #34 (W455-0045) +$64.70 QTY:
58- MAIN BURNER ORIFICE - LP #53 (W455-0033) +$64.70 QTY:
59- MANIFOLD TUBE WITH FITTINGS [REAR] (W432-0036) +$47.05 QTY:
60- MAINFIOLD TUBE WITH FITTINGS [FRONT] (W432-0036) +$47.05 QTY:
61- VALVE - ROBERTSHAW - NG [BEFORE S/N 016340] (W725-0028) +$598.46 QTY:
62- VALVE - ROBERTSHAW - LP [BEFORE S/N 016340] (W725-0029) +$730.96 QTY:
63- PILOT ORIFICE [SIT] - NG #51 (W455-0023) +$55.42 QTY:
64- PILOT ASSEMBLY - NG [PSE] [STRIPPED BROWN] (W010-0636) +$304.98 QTY:
65- PILOT ORIFICE [PSE] - NG (W455-0062) +$43.15 QTY:
66- PILOT ORIFICE [SIT] - LP #30 (W455-0024) +$54.85 QTY:
67- PILOT ASSEMBLY - LP [PSE] [STRIPPED DOWN] ~Old Part # W010-0575~ (W010-0799) +$218.05 QTY:
68- PILOT ORIFICE [PSE] - LP (W455-0052) +$43.15 QTY:

ITEMS NOT SHOWN


Item Description (Part Number)

70- TURBO BURNER ORIFICE - NG [HIGH ALTITUDE] #45 (W456-0045) +$47.05 QTY:
71- TURBO BURNER ORIFICE - LP [HIGH ALTITUDE] #59 (W456-0059) +$64.70 QTY:
72- MAIN BURNER ORIFICE - NG [HIGH ALTITUDE] #36 (W456-0036) +$58.20 QTY:
73- MAIN BURNER ORIFICE - LP [HIGH ALTITUDE] #53 (W456-0053) +$64.70 QTY:
74- GASKET - BLOWER ACCESS/RELIEF DOOR (W290-0032) +$37.31 QTY:
75- PEDESTAL TRIM - GOLD [FROM AR50G] (W715-0195-SER) +$54.85 QTY:
76- PEDESTAL TRIM - SATIN CHROME [FROM AR50SS] (N715-0045) +$32.92 QTY:
77- HINGE SPRING (W330-0025) +$43.64 QTY:
78- CONVERSION KIT - NG TO LP [ROBERTSHAW VALVE, BEFORE S/N 16340] (W175-0118) +$401.59 QTY:
79- CONVERSION KIT - LP TO NG [ROBERTSHAW VALVE, BEFORE S/N 16340] (W175-0137) +$240.21 QTY:
80- CONVERSION KIT - NG TO LP [ROBERTSHAW] HIGH ALTITUDE (W175-0121) +$417.43 QTY:
81- CONVERSION KIT - LP TO NG [ROBERTSHAW] HIGH ALTITUDE (W175-0061) +$197.03 QTY:
82- CONVERSION KIT - NG TO LP [SIT VALVE, AFTER S/N 016339] (W175-0231) +$186.00 QTY:
83- CONVERSION KIT - LP TO NG [SIT VALVE, AFTER S/N 016339] (W175-0232) +$237.81 QTY:
84- OWNERS MANUAL [hard copy] [W415-1427] (OMHC-N) +$21.99 QTY:
85- OWNERS MANUAL [electronic copy] [W415-1427] (OMEL-N) +$9.99 QTY:
