Item Description (Part Number) 1- NAPOLEON LOGO (W385-2010) +$43.15 QTY:
GLASS/GASKET/DOOR
Item Description (Part Number) 2- GLASS WITH GASKET (W010-1071) +$262.55 QTY: 2A- GLASS GASKET (W020-0050) +$64.70 QTY: 3- DOOR GASKET (W020-0044) +$133.41 QTY: 5- SPRING DOOR HANDLE [BLACK] (W325-0043) +$37.31 QTY:
ITEMS NOT SHOWN - GLASS/GASKET/DOOR
Item Description (Part Number) 30- RETAINER, GLASS - UPPER (W160-0077) +$37.31 QTY: 31- RETAINER, GLASS - LOWER ~Old Part # W500-0075~ (W500-0075-SER) +$11.21 QTY: 32- SIDE GLASS SUPPORT [2 per unit, each sold separately] (W500-0614) +$33.41 QTY: 33- SCREW FOR DOOR GLASS RETAINERS [5 per unit, each sold separately] (W570-0085) +$31.14 QTY: 34- DOOR FRAME - BLACK (W225-0040K) +$336.14 QTY: 34A- DOOR FRAME - METALLIC (W225-0040M) +$614.28 QTY: 34B- DOOR FRAME - GOLD PLATED (W225-0040G) +$866.52 QTY: 34C- DOOR FRAME - SATIN CHROME (W225-0040SC) +$1703.43 QTY: 35- DOOR HANDLE COMPLETE ASSEMBLY [NO SPRING HANDLE] (W020-0078) +$109.27 QTY: 36- DOOR HANDLE [SHAFT] (W325-0045) +$39.26 QTY: 37- AIR CONTROL SPRING HANDLE [BLACK] (W325-0042) +$31.46 QTY: 38- HINGE PIN - DOOR [2 per unit, each sold separately] (W545-0003) +$43.15 QTY:
EXTERNAL COMPONENTS
Item Description (Part Number) 4- ASH LIP (W135-0238) +$258.20 QTY: 6- AIR CONTROL HANDLE (W325-0044) +$31.46 QTY: 7- LOUVRES, LOWER - METALLIC BLACK [LONGER] (W715-0036) +$47.05 QTY: 7A- LOUVRES, UPPER - METALLIC BLACK [SHORTER] (W715-0346) +$60.99 QTY:
ITEMS NOT SHOWN - EXTERNAL COMPONENTS
Item Description (Part Number) 40- CANOPY - METALLIC BLACK (W010-2584) +$481.83 QTY: 40A- CANOPY - PORCELAIN BLACK (W010-0220K) +$559.58 QTY: 41- LEFT SIDE PANEL - HERITAGE [METALLIC BLACK] (W585-0214) +$205.59 QTY: 41A- LEFT SIDE PANEL - HERITAGE [PORCELAIN BLACK] (W585-0159K) +$276.79 QTY: 42- RIGHT SIDE PANEL - HERITAGE [METALLIC BLACK] (W585-0215) +$205.59 QTY: 42A- RIGHT SIDE PANEL - HERITAGE [PORCELAIN BLACK] (W585-0160K) +$248.31 QTY: 43- ASH PAN FRONT COVER - METALLIC BLACK (W010-1717) +$66.56 QTY: 44- ASHPAN FRONT COVER - PORCELAIN BLACK (W200-0156K) +$129.70 QTY: 8- TRIVET (W200-0077) +$80.18 QTY: 9- ASH PAN HANDLE (W325-0011) +$39.26 QTY: 10- ASH PAN ASSEMBLY ~Old Part # W010-0243~ (W325-0028) +$49.00 QTY:
BRICK/FIREBOX COMPONENTS
Item Description (Part Number) 11- BRICK [1.25 INCHES X 9 INCHES X 4.5 INCHES] [9 per unit, each sold separately] (W090-0001) +$37.31 QTY: 12- BRICK [1.25 INCHES X 9 INCHES X 3 INCHES] [2 per unit, each sold separately] (W090-0002) +$45.10 QTY: 13- BRICK [1.25 INCHES X 9 INCHES X 3 INCHES] [2 per unit, each sold separately] (W090-0166) +$50.95 QTY: 14- LEFT SIDE NOTCHED FIREBRICK [1.25 INCHES X 4.5 INCHES X 9 INCHES] (W090-0207) +$52.90 QTY: 15- RIGHT SIDE NOTCHED FIREBRICK [1.25 INCHES X 4.5 INCHES X 9 INCHES] (W090-0208) +$52.90 QTY: 16- BRICK [1.25 INCHES X 9 INCHES X 2.25 INCHES] (W090-0018) +$41.21 QTY: 17- BRICK [1.25 INCHES X 6.125 INCHES X 2.25 INCHES] (W090-0019) +$38.28 QTY: 18- BRICK [1.25 INCHES X 4.5 INCHES X 2.5 INCHES] (W090-0016) +$47.05 QTY: 19- BRICK [1.25 INCHES X 4.5 INCHES X 1.5 INCHES] (W090-0017) +$52.90 QTY: 20- BRICK [1.25 INCHES X 4.5 INCHES X 8.25 INCHES] [12 per unit, each sold separately] ~Old Part # W090-0184~ (W090-0210) +$23.15 QTY: 21- BRICK SET COMPLETE (W580-0002) +$725.84 QTY: 22- FIBER BAFFLE KIT (W010-3561) +$257.21 QTY: 23- PEDESTAL TRIM [5 FT] (W010-0349) +$72.13 QTY: 24- AIRWASH GASKET AND SHIELD (W010-0347) +$124.12 QTY: 25- MANIFOLD (W432-0142) +$282.14 QTY: 26- MANIFOLD GASKET ~Old Part # W290-0219~ (W290-0010) +$37.31 QTY:
ITEMS NOT SHOWN - BRICK/FIREBOX COMPONENTS
Item Description (Part Number) 50- BRICK RETAINER - REAR (W500-0076) +$43.80 QTY: 51- SCREW - FOR MANIFOLD & SHIELD (W570-0058) +$31.46 QTY: 52- SCREW - FOR MANIFOLD & SHIELD [2 per unit, each sold separately] (W570-0007) +$39.26 QTY: 53- MANIFOLD SHIELD & SCREWS (EP-14MS) +$186.00 QTY: 54- AIRWASH GASKET AND SHIELD KIT (W010-0347) +$124.12 QTY:
MISCELLANEOUS PARTS
Item Description (Part Number) 27- FAN (GZ552) +$417.43 QTY: 28- VARIABLE SPEED SWITCH KIT (KB-35) +$99.98 QTY:
ITEMS NOT SHOWN - MISCELLANEOUS PARTS
Item Description (Part Number) 55- ASHWELL SPRING (W630-0004) +$52.90 QTY: 56- FRESH AIR COVER PLATE (W500-0064) +$68.25 QTY: 57- PEDESTAL BACK PLATE ~Old Part # W475-0217~ (W475-0217M-SER) +$102.86 QTY: 58- SPRING HANDLE - DAMPER ROD [SMALL-BLACK] (W325-0042) +$31.46 QTY: 59- DAMPER ROD LABEL [HI/LOW] (W385-0312) +$83.27 QTY: 60- INSTRUCTION MANUAL - PEDESTAL MODELS (W415-0763) +$40.63 QTY:
|
